Product Details:
|
| Model NO.: | WIND-2-SW | 2pole Stator Winding: | Engineers Avaiable To Service Overseas |
|---|---|---|---|
| Condition: | New | Customized Service: | Provided |
| Loading/Unloading: | By Hand | Winding Indexing: | Fully Automatically |
| Transport Package: | Wooden Case | Specification: | Middle Size |
| Trademark: | Wind Automation | Origin: | China |
| HS Code: | 8479811000 | Production Capacity: | 100 Sets/Year |
| Package Size: | 1500.00cm * 800.00cm * 1780.00cm | Package Gross Weight: | 780.000kg |
| Wire diameter | 0.25~0.8mm |
| Stator OD | 50~90mm |
| Stator ID | 30~50mm |
| Stack height | 20~45mmm |
| Pole No. | Two |
| Movement | Stepping/Auto |
| Voltage | AC380V,50/60Hz |
| Air pressure | 0.4~0.7MPa |
| Weight | 1800Kg |
| Dimension | 2100x1250x1830mm |
