900 Kg Straight Bar Linear Segment Stator Needle Winding Machine for Smooth Operation

Large Image : 900 Kg Straight Bar Linear Segment Stator Needle Winding Machine for Smooth Operation

Product Details:

Contact Now

900 Kg Straight Bar Linear Segment Stator Needle Winding Machine for Smooth Operation

Description

Model NO.:	WIND-ZR158	Automation Type:	Fully Automatic
Color:	Customized	Power:	8 W
Voltage:	380V	Weight:	900 Kg
Dimension:	1100X800X2000mm	Air Source:	0.4~0.7 MPa
Transport Package:	Wooden Case	Specification:	Middle Size
Trademark:	Wind Automation	Origin:	China
HS Code:	8479811000	Production Capacity:	100 Sets/Year
Package Size:	1800.00cm * 1900.00cm * 2100.00cm	Package Gross Weight:	800.000kg

Straight Bar Linear Segment Stator Needle Winding Machine

This type of needle winding machine is designed for stators with narrow slot but high slot filling rate. During winding, turn number in each layer can be flexibly changed to meet different requirements of various model types.

(1) Features
Friendly designed operator's interface
2 working stations to do synchronous winding
High efficiency and production
Precise servo drive control of the wire feeding
High quality level of the winding process
No-loading speed up to 600r/min
Provide customized service

(2) Specification

Working station	2
Stator OD	Max 400mm
Stack length	Max 100mm
Stator weight	Max 3KG
Wire range	0.1-0.8mm
Winding speed	600rpm
Power	8 KW
Air source	0.4~0.7 MPa
Power supply	AC 380±10, 50/60HZ
Dimension	1100x800x2000mm
Weight	900KG

(3) Application
It is suitable for various kinds of open slot stators with high slot filling rate.

(4) For Winding Machine price
Segmented stator winding details is needed

(4) For Winding Machine WIND-ZR158 cycle time

1) 0.19mm wire size, 600 turns per slot, 12 slots, 2pcs/7minutes

2) 0.56mm wire size, 68turns per slot, 9slots, 2pcs/1.5minutes

Contact Details

Shanghai Wind Automation Equipment Co.,Ltd
